💡 A heated Cooling Unit is easier to disassemble because the steam condensate can be sticky.
| Pull the Cap Lock towards the Mouthpiece. | |
| Pull the Cooling Unit Cap from the Vaporizer. | |
Pull the Mouthpiece out of the Cooling Unit Cap by tilting it slightly back and forth. Pull off the Mouthpiece Seal Ring | |
When cleaning the Cooling Unit Cap in isopropyl alcohol, remove the Cap Lock by pulling it up on one side. First press the Cap Lock on one side and pull it up on the opposite side. | |
Then slide the Cap Lock on the raised side towards the opposite side. â–º The signet hologram on the Cap Lock is a sticker | |
| Unscrew the Cooling Unit Base from the Vaporizer by turning it 90° counterclockwise | |
Lever out the large Base Seal Ring with the Filling Chamber Tool at the recess in the groove. Remove the small Base Seal Ring | |
| Press the upper Screen with the Filling Chamber Tool from the top to the bottom out of the Cooling Unit base. |
💡 To reassemble follow the instruction in reverse order!
💡 Please Note:
When assembling, make sure that Seal Rings are properly seated.
â–º The small Base Seal Ring, especially, must sit completely in the Cooling Unit Cap and be no longer visible.
Carefully insert the upper Screen into the groove provided
â–º Disregarding this may allow plant particles to enter the Cooling Unit, so blocking this or be inhaled
- Using the Filling Chamber Tool, press the screen flat into the provided groove
