LED Display Options


Charging / Switch-Off – LED Display
  • Continuous blue light
    ► Battery is fully charged

  • Blue blinking or flashing
    ► Charging status (during the charging operation or following switch off*)

  • Green/red/blue (short illumination)
    ► Start of the charging process

  • Blue and yellow** blinking
    ► Charging with USB-C to USB-A cable

  • Blue and magenta** blinking
    ► Charging with a low power charger

  • Blue and green** blinking
    ► ECO charging mode

*After switching off, the LED indicator lights up, blinks, or flashes for about 10 seconds.
**Lower LED; on every 10th blinking cycle

For each charging mode, the flashing frequency indicates the charging status of the battery:

  • Slowly blinking: 61 and 98%
  • Rapidly blinking: 31 and 60%
  • Blue flashing: max. 30%

Read more: Charging

Heating / Adjusting Temperatures – LED Display
  • Continuous orange light
    ► Heating (Base Temperature)

  • Continuous green light
    ► Base Temperature has been reached

  • Orange blinking (slowly)
    ► Heating (Booster Temperature)

  • Continuous Green Light of lower LED
    ► Boost Temperature has been reached

  • Orange blinking (rapidly)
    ► Heating (Superbooster Temperature)

  • Continuous Green Light of upper LED
    ► Super Boost Temperature has been reached

Read more: Temperature Settings

Reset – LED Display

Green/red/blue (running lights)

Read more: Resetting the VEAZY

Faults – LED Display
  • Continuous red light (lower LED) and white/blue blinking (upper LED)
    ► Device temperature is too high.
    ► Let the Vaporizer cool down.

  • White/blue blinking (lower LED) and continuous red light (upper LED)
    ► Device temperature is too low.
    ► Move the Vaporizer to a warm environment. (Do not heat the Vaporizer with an external heat!)

  • Continuous red light (lower LED) and white/red blinking (upper LED)
    ► USB charger or USB-C cable is not suitable.
    ► Only use original STORZ & BICKEL accessories.

  • Continous white light (both LEDs)
    ► Vaporizer is faulty.
    ► Switch off the Vaporizer immediately.
    ► Pull out the plug.
    ► Contact our Service Center.

  • Continuous red light (lower LED) and continous white light (upper LED)
    ► Firmware update did not work, retry update.
    ► Perform the firmware update. If the update fails multiple times, please contact our Service Center.
Bluetooth® – LED Display
  • Blue blinking
    ► BLE connection

  • Continuous blue light
    ► Device is connected
"Find my device" – LED Display

Green/red/blue (running lights)

Read more: Main Features of the S&B Web App
